Camera |
|
Image Device |
¼“ Cmos Progressive 1.3 Mega-pixel image sensor |
|
Effective Pixels |
1280 x 1024 pixels |
|
Sensitivity |
1.0V/lux-sec (550nm) |
|
Signal to Noise |
44dB |
|
Lens |
Board fixed Mega Lens
2.8mm/F2.0
Horizontal Angle of View: 78º
Optional Lenses:
2.1mm = 100º
3.6mm = 58º
6mm = 33º
8mm = 25º
12mm = 17º
16mm = 12º |
|
|
|
|
|
|
|
|
|
IP Module |
|
Video |
|
Video Encoder |
H.264, MPEG4 and Motion JPEG simultaneously (Tri-encoders) |
|
Video Profile |
11 profiles simultaneously
- H.264 SXGA/ VGA / QVGA / QVGA
- MPEG4 VGA / QVGA / QVGA
- M-JPEG SXGA/ VGA / QVGA / QVGA |
|
Frame Rate |
Mega-pixel mode: Up to 15fps for all 11 profiles
VGA mode: Up to 30fps for all 9 profiles |
|
Image Setting |
De-noise
Brightness, sharpness, contrast
Text, time and date overlay |
|
Streaming |
Simultaneously multi-profile streaming
Streaming over UDP, TCP, or HTTP
Multicast streaming
M-JPEG streaming over HTTP
Supports 3GPP mobile surveillance
Controllable frame rate and bandwidth
Constant and variable bit rate (MPEG4 / H.264) |
|
Audio |
|
Audio Encoder |
RTSP: G.711 64kbps, G.726 32kbps
3GPP: AMR |
|
Audio Streaming |
One-way or two-way |
|
Microphone |
External microphone input |
|
Audio Output |
Line level out |
|
Network |
|
Supported Protocols |
TCP, UDP, HTTP, SMTP, FTP, NTP, DNS, DDNS, DHCP, ARP, Bonjour, UPnP, RTSP, RTP, RTCP, PPPoE, 3GPP, ICMP, SAMBA |
|
Security |
Password protection, IP address filtering, user access log |
|
Users |
20 simultaneous unicast users
Unlimited users using multicast |
|
Ethernet |
10/100M auto negotiation |
|
System Integration |
|
Application Programming Interface |
Open API for software integration
SDK |
|
Alarm Triggers |
Intelligent video motion detection and external input |
|
Motion Detection |
10-zone video motion detection |
|
Alarm Events |
File upload via FTP or email
Notification via email, HTTP, and TCP
External output activation
Go to PTZ preset position
Audio alerting output |
|
Video Buffer |
Pre- and post- alarm buffering |
|
General |
|
RAM |
128MB |
|
ROM |
8MB |
|
Power Supply |
12V DC external power adapter |
|
PoE |
IEEE 802.3af (for wired model only) |
|
Power Consumption |
3W max |
|
Connectors |
RJ-45 10BaseT/100BaseTX
DC jack
1 alarm input and 1 output
Audio in/out
RS485 |
|
Indication LED |
Two LEDs |
|
Protection Class |
Indoor use |
|
Construction |
3-axis mechanical design |
|
Operating Temperature |
0ºC to 40ºC (32ºF to 104ºF) |
|
Operating Humidity |
20% ~ 80% (non-condensing) |
|
Dimension |
TBD |
|
Viewing System |
|
OS |
Windows® 2000, XP, Vista |
|
Browser |
IE 6.0 or latter / Firefox 2.0 or later |
|
Cell Phone |
With 3GPP player |
|
Video Player |
VLC, Quick Time, Real Player |
|
Software |
|
Search & Installation |
IPWizard-2 |
|
Bundled NVR Program |
SecuGuard 16CH Basic |
